Product Details:
|
| Model: | 120M | Year: | 2005-2015 |
|---|---|---|---|
| OE NO.: | 2698325 | Car Fitment: | CATERPILLAR |
| Material: | Fiberglass Paper | Type: | Lube Oil Filter |
| Size: | 93 Mm*200 Mm | Reference NO.: | P550920 |
| Truck Model: | LOADER WHEELED | Application: | Hydraulic System |
| Product Name: | Hydraulic Oil Filter Element | Filter Material: | Glass Fiber Filter Material |
| Service: | Professional Services | Usage: | Remove Oil Impurities |
| Color: | Custermized | Package: | Original Package |
| MOQ: | 10 | WORK LIFE: | 2000- 4000h |
| After Warranty Service: | Online Support | Port: | Tian Jin Port |
Outer Diameter | 93 mm (3.66 inch) | |
Thread Size | M24 x 1.5 | |
Length | 200 mm (7.87 inch) | |
Gasket OD | 72 mm (2.83 inch) | |
Gasket ID | 62 mm (2.44 inch) | |
Efficiency 99% | 26 micron | |
Efficiency Test Std | ISO 16889 | |
Anti-Drainback Valve | Yes | |
Bypass Valve | Yes | |
Bypass Valve Setting LR | 2.1 bar (30 psi) | |
Bypass Valve Setting HR | 2.55 bar (37 psi) | |
Media Type | Cellulose | |
Type | Full-Flow | |
Style | Spin-On | |
Primary Application | CATERPILLAR 2698325 | |
Packaged Length | 3.7 IN | |
Packaged Width | 3.7 IN | |
Packaged Height | 7.9 IN | |
Packaged Weight | 1.35 LB | |
Packaged Volume | 0.05763527 FT3 |
