Product Details:
|
| Model: | 3516, 3512, 3508 | Year: | 1986-1993, 1986-1993, 1986-1993 |
|---|---|---|---|
| OE NO.: | B085001 | Car Fitment: | CATERPILLAR |
| Material: | Filter Paper, Iron | Type: | Air Filter |
| Size: | 216*216*279 | Reference NO.: | B085001 |
| Truck Model: | ENGINE | Product Name: | Engine Air Filter |
| Application: | Diesel Air System | Quality: | High-Quality |
| Packing: | Neutral Packing Or Customized | MOQ: | 1 PC |
| Service: | Online Service | Brand: | Hydwell |
| Filter Type: | Air Filter Elements | DELIVERY TIME: | 7-15 Days |
| Port: | Tainjin |
Outlet Diameter | 76.2 mm (3.00 inch) | |
Body Diameter Maximum | 216 mm (8.50 inch) | |
Body Length | 279 mm (10.98 inch) | |
Efficiency | 99.9 | |
Efficiency Test Std | ISO 5011 | |
Rated Flow LR | 7.8 m³/min (275 cfm) | |
Rated Flow MR | 9.5 m³/min (335 cfm) | |
Rated Flow HR | 11 m³/min (388 cfm) | |
Restriction LR | 102 mm H2O (4.02 inch H2O) | |
Restriction MR | 152 mm H2O (5.98 inch H2O) | |
Restriction HR | 203 mm H2O (7.99 inch H2O) | |
Family | ECB |
